1. 端部仕上げ
22φ〜32φ：ラフカット+口焼き
35φ〜54φ：プレーンカット+口焼き
1. edge finish
22φ - 32φ : Rough cut + mouth burnishing
35φ - 54φ : Plain cut + mouth burnishing
| 品種コード | (参照薄肉管) | 外径(mm) | ±(mm) | 肉厚(mm) | ±(mm) | 箱入数(本/箱) | 箱重量(Kg/箱) |
|---|---|---|---|---|---|---|---|
| LW22TH | - | 22 | 0.3 | 1.2 | 0.1 | 50 | 13.2 |
| LW24TH | CZ024121506 | 24 | 0.4 | 1.2 | 0.1 | 40 | 11.5 |
| LW30TH | - | 30 | 0.5 | 1.3 | 0.15 | 40 | 15.7 |
| LW32TH | - | 32 | 0.5 | 1.3 | 0.15 | 30 | 12.6 |
| LW35NP | - | 35 | 0.6 | 1.3 | 0.15 | 24 | 11.2 |
| LW36NP | CZ036141506 | 36 | 0.6 | 1.4 | 0.15 | 24 | 12.4 |
| LW38NP | - | 38 | 0.6 | 1.5 | 0.15 | 18 | 10.5 |
| LW40NP | - | 40 | 0.6 | 1.5 | 0.15 | 20 | 12.3 |
| LW42NP | CZ042161506 | 42 | 0.7 | 1.6 | 0.15 | 16 | 11.0 |
| LW44NP | - | 44 | 0.7 | 1.6 | 0.15 | 16 | 11.5 |
| LW45NP | - | 45 | 0.7 | 1.6 | 0.15 | 16 | 11.8 |
| LW46NP | - | 46 | 0.7 | 1.6 | 0.15 | 16 | 12.1 |
| LW48NP | CZ048161506 | 48 | 0.8 | 1.6 | 0.15 | 16 | 12.6 |
| LW50NP | CZ050161506 | 50 | 0.8 | 1.6 | 0.15 | 16 | 13.2 |
| LW52NP | - | 52 | 0.8 | 1.8 | 0.15 | 12 | 11.5 |
| LW54NP | - | 54 | 0.8 | 1.8 | 0.15 | 8 | 7.9 |
