端部仕上げ
ラフカット+口焼き (CZ045401506RCを除く)
CZ045401506RC: ラフカットのみ
edge finish
Rough cut + mouth burnishing (except CZ045401506RC)
CZ045401506RC: Rough cut only
| 品種コード | (参照厚肉管B) | 外径(mm) | ±(mm) | 肉厚(mm) | ±(mm) | 箱入数(本/箱) | 箱重量(kg/箱) |
|---|---|---|---|---|---|---|---|
| CZ010221506 | HW10TH | 10 | 0.2 | 2.2 | 0.15 | 64 | 11.5 |
| CZ011221506 | HW11TH | 11 | 0.2 | 2.2 | 0.15 | 50 | 10.2 |
| CZ012201506 | HW12TH | 12 | 0.2 | 2.0 | 0.15 | 49 | 10.3 |
| CZ016241506 | HW16TH | 16 | 0.2 | 2.4 | 0.15 | 49 | 16.9 |
| CZ020401506 | HW20TH | 20 | 0.4 | 4.0 | 0.4 | 36 | 24.2 |
| ＊CZ022321506 | HW22TH | 22 | 0.45 | 3.2 | 0.25 | 36 | 22.9 |
| CZ028401506 | HW28TH | 28 | 0.6 | 4.0 | 0.4 | 16 | 16.1 |
| ＊CZ030401506 | HW30TH | 30 | 0.65 | 4.0 | 0.25 | 16 | 17.6 |
| CZ036401506 | HW35TH | 36 | 0.8 | 4.0 | 0.4 | 16 | 21.5 |
| CZ040501506 | HW40NP | 40 | 0.8 | 5.0 | 0.4 | 9 | 16.6 |
| CZ045401506 | HW45NP | 45 | 0.8 | 4.0 | 0.3 | 9 | 15.6 |
| CZ045401506RC | HW45NP | 45 | 0.8 | 4.0 | 0.3 | 9 | 15.6 |
| CZ055501506 | HW55NP | 55 | 0.8 | 5.0 | 0.4 | 9 | 23.6 |
| CZ060501506 | HW60TH | 60 | 0.8 | 5.0 | 0.4 | 4 | 11.6 |
| CZ070481506 | HW70NP | 70 | 1.2 | 4.8 | 0.4 | 4 | 13.2 |
| CZ075481506 | HW75NP | 75 | 1.2 | 4.8 | 0.4 | 4 | 14.2 |
| CZ080501506 | HW80NP | 80 | 1.2 | 5 | 0.5 | 4 | 15.8 |
| CZ085501506 | HW85NP | 85 | 1.5 | 5 | 0.5 | 4 | 16.8 |
| CZ090501506 | HW90NP | 90 | 1.5 | 5 | 0.5 | 4 | 17.9 |
| CZ095501506 | HW95NP | 95 | 1.5 | 5 | 0.5 | 4 | 18.9 |
| CZ100641506 | HW100NP | 100 | 1.5 | 6.4 | 0.6 | 3 | 18.9 |
| CZ110641506 | HW110NP | 110 | 1.8 | 6.4 | 0.6 | 3 | 21.0 |
| CZ120701506 | HW120NP | 120 | 1.5 | 7 | 0.8 | 3 | 25.0 |
| CZ140701506 | HW140NP | 140 | 1.7 | 7 | 0.9 | 2 | 19.6 |
| CZ150701506 | HW150NP | 150 | 1.8 | 7 | 0.9 | 1 | 10.6 |
| CZ165701506 | HW165NP | 165 | 1.8 | 7 | 1 | 1 | 11.7 |
| CZ180901506 | HW180NP | 180 | 2 | 9 | 1.2 | 1 | 16.2 |
