1. 端部仕上げ
2φ〜6φ ：ラフカットのみ
7φ〜35φ：ラフカット+口焼き
36φ〜95φ：プレーンカット+口焼き
100φ〜 ：プレーンカットのみ
1. edge finish
2φ - 6φ : Rough cut only
7φ - 35φ : Rough cut + mouth burnishing
36φ-95φ : Plain cut + mouth burnishing
100φ- : Plain cutting only
| 品種コード | (参照標準管) | 外径(mm) | ±(mm) | 肉厚(mm) | ±(mm) | 箱入数(本/箱) | 箱重量(Kg/箱) |
|---|---|---|---|---|---|---|---|
| STD10TH | CZ010101506 | 10 | 0.2 | 1 | 0.1 | 104 | 9.9 |
| STD11TH | CZ011101506 | 11 | 0.2 | 1 | 0.1 | 77 | 8.1 |
| STD12TH | CZ012101506 | 12 | 0.2 | 1 | 0.1 | 126 | 14.6 |
| STD13TH | - | 13 | 0.2 | 1.2 | 0.1 | 104 | 15.5 |
| STD14TH | CZ014121506 | 14 | 0.2 | 1.2 | 0.1 | 95 | 15.4 |
| STD15TH | CZ015121506 | 15 | 0.2 | 1.2 | 0.1 | 91 | 15.9 |
| STD16TH | CZ016121506 | 16 | 0.2 | 1.2 | 0.1 | 78 | 14.6 |
| STD17TH | CZ017121506 | 17 | 0.2 | 1.2 | 0.1 | 78 | 15.6 |
| STD18TH | CZ018121506 | 18 | 0.2 | 1.2 | 0.1 | 78 | 16.6 |
| STD19TH | CZ019121506 | 19 | 0.2 | 1.2 | 0.1 | 65 | 14.6 |
| STD20TH | CZ020121506 | 20 | 0.3 | 1.2 | 0.1 | 60 | 14.3 |
| STD22TH | CZ022151506 | 22 | 0.3 | 1.5 | 0.15 | 50 | 16.2 |
| STD23TH | - | 23 | 0.4 | 1.5 | 0.15 | 40 | 13.6 |
| STD25TH | CZ025151506 | 25 | 0.4 | 1.5 | 0.15 | 40 | 14.9 |
| STD26TH | CZ026151506 | 26 | 0.4 | 1.5 | 0.15 | 32 | 12.4 |
| STD28TH | - | 28 | 0.4 | 1.5 | 0.15 | 32 | 13.4 |
| STD30TH | CZ030181506 | 30 | 0.5 | 1.8 | 0.15 | 32 | 17.1 |
| STD32TH | CZ032181506 | 32 | 0.5 | 1.8 | 0.15 | 30 | 17.2 |
| STD35TH | CZ035201506 | 35 | 0.5 | 2 | 0.15 | 24 | 16.7 |
